Architect Blackout Roller Shades

Product Details

Description

Achieve the ultimate darkness and privacy in any space with Architect Blackout Roller Shades from Select Blinds. Perfect for bedrooms, nurseries, and media rooms, these sleek blackout roller shades are crafted to minimize incoming light while seamlessly blending with a range of interior styles. In the Select Colors section, you’ll discover a variety of neutral hues, dramatic tones, and subtle patterns, ensuring you find the ideal match for your décor.

Why They Are Loved

Customization Options

Cordless Lift: Eliminate dangling cords for a neat, child-safe solution that’s easy to operate.
Continuous Loop Lift: Enjoy consistent tension and effortless movement—particularly suitable for larger or heavier shades.
Motorized Lift: Control your blinds with a simple push of a button, perfect for hard-to-reach windows or a modern edge.
Roll Position: Choose standard roll for a streamlined appearance or reverse roll to showcase more of the shade’s fabric at the front.
Headrails: Upgrade with an aluminum fascia or a cassette headrail to discreetly hide hardware and achieve a refined finish.
Click2Fit Installation: Say goodbye to screws and brackets. These shades securely mount inside the window frame using a pressure-fit headrail—perfect for renters and DIYers.

The Select Blinds Difference

DIY-friendly

Handcrafted to order

Free shipping

Measuring protection guarantee

Free 3 year limited warranty

Select Blinds is committed to making home improvement easy and accessible. Our DIY-friendly design ensures a straightforward installation process, and every product is shipped free to your doorstep for your convenience.

With over 170 products and 1,800 colors to choose from, Select Blinds offers unmatched variety and quality in custom window treatments. Each product is handcrafted with care to ensure exceptional results you’ll love.

Specifications

Width

8" - 120"

*Varies by lift style

Height

20" - 120"

*Varies by lift style

Depth

2 1/2" Min

*Varies by lift style

Headrail Height

3 1/2"-4"

*Varies by lift style

Dimensions by Configuration

Configuration	Width	Height	Required Mounting Space	Cassette Dimensions
Continuous Cord Loop	8"- 108"	20"- 120"	Inside Mount Minimum Depth: 2 1/2" Exposed Roll, 4" Aluminum Fascia , 2 1/2" Cassette Inside Mount Flush Depth: 3 3/8" Exposed Roll, 4 3/8" Aluminum Fascia, 4 1/4" Cassette Outside Mount Minimum Space: 2 1/2" Exposed Roll, 4" Aluminum Fascia, 2 3/4" Cassette	Aluminum Fascia: 4 3/8" H Semi-Open: 3 1/2" H, 3 5/8" D Cassette w/ Fabric Insert: 4" H, 4" D
Cordless Lift	22"- 96"	20"- 96"	Inside Mount Minimum Depth: 2 1/2" Exposed Roll, 4" Aluminum Fascia , 2 1/2" Cassette Inside Mount Flush Depth: 3 3/8" Exposed Roll, 4 3/8" Aluminum Fascia, 4 1/4" Cassette Outside Mount Minimum Space: 2 1/2" Exposed Roll, 4" Aluminum Fascia, 2 3/4" Cassette	Aluminum Fascia: 4 3/8" H Semi-Open: 3 1/2" H, 3 5/8" D Cassette w/ Fabric Insert: 4" H, 4" D
Pull Wand Motorization	24"- 72"	20"- 96"	Inside Mount Minimum Depth: 2 1/2" Exposed Roll, 4" Aluminum Fascia , 2 1/2" Cassette Inside Mount Flush Depth: 3 3/8" Exposed Roll, 4 3/8" Aluminum Fascia, 4 1/4" Cassette Outside Mount Minimum Space: 2 1/2" Exposed Roll, 4" Aluminum Fascia, 2 3/4" Cassette	Aluminum Fascia: 4 3/8" H Semi-Open: 3 1/2" H, 3 5/8" D Cassette w/ Fabric Insert: 4" H, 4" D
Wireless Pull Wand Motorization	22"- 108"	20"- 120"	Inside Mount Minimum Depth: 2 1/2" Exposed Roll, 4" Aluminum Fascia , 2 1/2" Cassette Inside Mount Flush Depth: 3 3/8" Exposed Roll, 4 3/8" Aluminum Fascia, 4 1/4" Cassette Outside Mount Minimum Space: 2 1/2" Exposed Roll, 4" Aluminum Fascia, 2 3/4" Cassette	Aluminum Fascia: 4 3/8" H Semi-Open: 3 1/2" H, 3 5/8" D Cassette w/ Fabric Insert: 4" H, 4" D
Click2Fit No-Drill	18"-72"	20-60"	Inside Mount Minimum Depth: 2 3/8"	Exposed Roll: 2 3/4" H Semi-Open: 4" H Cassette w/ Fabric Insert: 4" H

Fit & Factory Deductions

Recommendations

No Drill

Good to Know

The rear color of each shade may not match the front of the shade. In most cases the Lifestyle Collection will be a similar color to the front while the other collections will be white or off-white.
Shades over 98" wide will have a horizontal seam when choosing colors from the Essential Collection. Seam is placed as high as possible on shade so, in most cases, it remains hidden.
Continuous Cord Loop is a color-coordinated cord with plastic beads.
Continuous Cord Loop will have a defaulted lift cord location to the left side.
The safety device is required by law and must be applied on chain loops and prevents free-hanging loops in operating chains. Install the safety device at the maximum distance possible from the control mechanism to prevent slack in the loop.
Products come with 10" - 14" of extra fabric to conceal roller.
Fascia and cassette colors coordinate with the color of hardware selected.
Cordless Shades ordered with the Solid Bottom Rail will have a handle attached, while Cordless Shades ordered with the Fabric Wrapped Bottom Rail do not have a handle.
Cornice Size on Inside mount will be 1/8'' smaller than the ordered width with no side returns and no brackets included.
Cornice Size on Outside mount will be 1 1/8'' larger than the ordered width with 3 1/2'' returns, brackets included.
For 2 Shades on 1 headrail there will be a 7/8" - 1" space between shades. Cord and Wand controls for these shades will be on opposite ends. .

Motorization

SelectConnect Bridge

The SelectConnect Bridge is compatible with almost all Motorization systems we offer. (Not compatible with Panel Tracks, Wood Blinds, or the SelectBlinds Automation system)
The SelectConnect Bridge is only compatible with remote-operated shades. (shades that use both Wand + Remote are compatible, Wand-only shades are not compatible)
You must have Wi-Fi access in areas where products are installed for controller to work.
Download of free Bond Home App on iOS (Apple) or Android devices required.
Controller range is approximately 150' or 30 blinds/shades. One controller per floor is recommended for use in typical size homes. However, multiple units may be needed for full coverage depending on the location of window coverings and the layout and construction materials of your home.
Please note this product is not covered under our FIT Guarantee.
Please note this product is not eligible for returns or refunds unless deemed defective. Contact Customer Service for more details.

Remote Motorization

Motorization remote and hub will always be black
A full battery charge will last up to 12 months based on an average-sized shade raised and lowered once a day
Battery life span is approximately 365 cycles on average
Shades comes fully charged with upper and lower limits preset
Motorized shades ship in "transportation" mode to prevent shade from accidentally operating. After installation the motor needs to be activated. See instructions to activate shade
It takes approximately 6 hours to recharge the motor when fully depleted
Motorization offers three remote options featuring a CR2430 battery
Remote comes programmed to the shade. If multiple shades are ordered they will all come programmed to the remote. One remote per room is recommended for convenience
Remote range will function up to 50 ft
Integrated Li-ion battery is rechargeable with a USB cable

Motorized Wand

Downloads

Motorization Instructions

Downloads

SelectConnect App Setup & Product Pairing Instructions

Measuring

Inside Mount Instructions

Measuring the width

The width measurement is taken from the inside edge of the window frame at the top.
If you are getting a 1/16” or 1/32” increment, round down to the nearest 1/8”. (For example, if the smallest measurement is 24 9/16", round down to 24 1/2". If it's 24 3/8", no need to round down.)
This will be the width you order.

Measuring the height

The height measurement is taken from the window frame in three places (top left, center, and top right down to the window sill).
Record the largest height out of the 3 measurements up to the nearest 1/8”.
If you are getting a 1/16” or 1/32” increment, round up to the nearest 1/8”. (For Example, If the largest measurement is 24 9/16", round up to 24 5/8". If it's 24 1/2", no need to round up.)
This will be the height you order.

Outside Mount Instructions

An outside mount is a great choice for better light coverage, since it fully covers the window and frame. To get the right fit, you’ll need to account for a few extra measurements when placing your order. We’ll custom make your shade to the exact dimensions you provide—no automatic additions are made.

Flat Surface Requirements

Start by choosing where you’d like to mount your shade. You’ll need at least 1-2½” of flat mounting space. For more details, check the product page and review the “Specifications” tab.

Measuring the width

Measuring the height

Measuring Tips

Downloads

Measure Instructions

Contact Customer Support

Shipping & Production

Expedite Your Order Today

Free Shipping on Everything

Freight Surcharge Chart	SelectBlinds	Other Retailers
Blinds and shades under 94" wide	Free	Free
Blinds and shades 94" wide & above	Free	$70 per oversize product
Vertical blinds 94" in height or width & above	Free	$70 per oversize product
Some Shutters	Free	$70 per oversize product
