Motorized Architect Blackout Roller Shades

Product Details

Upgrade your space with the clean lines, modern style, and total darkness of the Motorized Architect Blackout Roller Shades from Select Blinds. Engineered for convenience and style, these premium blackout shades feature a smart motorized lift, allowing you to block out light and enhance privacy at the push of a button—or even with voice control when integrated into your smart home system.

Why They Are Loved

Customization Options

Fully Customizable:
- Choose your roll position: standard or reverse
- Upgrade to a fabric-wrapped cornice board for a sleek, integrated finish
- Select your bottom rail: fabric wrapped or solid
- Upgrade the hardware to metal for an elevated look
Motorized Operation: Easily raise or lower your shades remotely, or schedule them to open and close automatically with your smart home devices.
Wide Range of Colors: Available in a sophisticated palette of textured and solid color options, the Select Colors section features choices that complement minimalist, modern, or transitional décor.
Precision Fit: Input your custom measurements through the “Measure Your Windows” section to ensure your shades fit perfectly, edge to edge.
Click2Fit Installation: Say goodbye to screws and brackets. These shades securely mount inside the window frame using a pressure-fit headrail—perfect for renters and DIYers

The Select Blinds Difference

DIY-friendly

Handcrafted to order

Free shipping

Measuring protection guarantee

Free 3 year limited warranty

Select Blinds is committed to making home improvement easy and accessible. Our DIY-friendly design ensures a straightforward installation process, and every product is shipped free to your doorstep for your convenience.

With over 170 products and 1,800 colors to choose from, Select Blinds offers unmatched variety and quality in custom window treatments. Each product is handcrafted with care to ensure exceptional results you’ll love.

Specifications

Width

22" - 96"

*Varies by lift style

Height

20" - 108"

*Varies by lift style

Depth

2 1/2"

*Minimum

Headrail Height

3 1/2"

*Varies by lift style

Dimensions by Configuration

Configuration	Width	Height	Required Mounting Space	Headrail Dimensions
Motorization	22" - 96"	20" - 108"	Inside Mount Minimum Depth: 2 1/2" Exposed Roll 4" Aluminum Fascia 2 1/2" Cassette Inside Mount Flush Depth: 3 3/8" Exposed Roll 4 3/8" Aluminum Fascia 4 1/4" Cassette Outside Mount Minimum Space: 2 1/2" Exposed Roll 4" Aluminum Fascia 2 3/4" Cassette	Aluminum Fascia: 4 3/8" Height Semi-Open Flat Cassette: 3 5/8" Depth 3 1/2" Height Cassette with Fabric Insert: 4" Depth 4" Height
Click2Fit No-Drill	18"-72"	20"-60"	Inside Mount Minimum Depth: 2 3/8"	Exposed Roll: 2 3/4" H Semi-Open: 4"H Cassette w/ Fabric Insert: 4" H

Fit & Factory Deductions

Recommendations

No Drill

Good to Know

The Lifestyle Collection has a matching front and back, providing a uniform look from both inside and outside.
The Essential Collection, Architect Collection, and Luxe Collection feature a white backing that contrasts with the front of the shade. This makes them an ideal choice for HOA communities that require neutral window coverings.
Shades over 98" wide will have a horizontal seam when choosing colors from the Essential Collection. Seam is placed as high as possible on shade so, in most cases, it remains hidden.
Products come with 10" - 14" of extra fabric to conceal roller.
Fascia and Cassette colors coordinate with the color of hardware selected.
Cornice Size on Inside mount will be 1/8'' smaller than the ordered width with no side returns and no brackets included.
Cornice Size on Outside mount will be 1 1/8'' larger than the ordered width with 3 1/2'' returns, brackets included.

Motorization

SelectConnect Bridge

The SelectConnect Bridge is compatible with almost all Motorization systems we offer. (Not compatible with Panel Tracks, Wood Blinds, or the SelectBlinds Automation system)
The SelectConnect Bridge is only compatible with remote-operated shades. (shades that use both Wand + Remote are compatible, Wand-only shades are not compatible)
You must have Wi-Fi access in areas where products are installed for controller to work.
Download of free Bond Home App on iOS (Apple) or Android devices required.
Controller range is approximately 150' or 30 blinds/shades. One controller per floor is recommended for use in typical size homes. However, multiple units may be needed for full coverage depending on the location of window coverings and the layout and construction materials of your home.
Please note this product is not covered under our FIT Guarantee.
Please note this product is not eligible for returns or refunds unless deemed defective. Contact Customer Service for more details.

Remote Motorization

Motorization remote will always be black
Integrated Li-ion battery is rechargeable with USB C cable
A full battery charge will last up to 12 months based on an average-sized shade raised and lowered once a day
Battery life span is approximately 365 cycles on average
Motorized shades ship in "transportation" mode to prevent shade from accidentally operating. After installation the motor needs to be activated. See instructions to activate shade
Shades comes fully charged with upper and lower limits preset
It takes approximately 6 hours to recharge the motor when fully depleted
Motorization offers three remote options featuring a CR2430 battery
Remote comes programmed to the shade. If multiple shades are ordered they will all come programmed to the remote. One remote per room is recommended for convenience
Remote range will function up to 50 ft
Motorized options are powered by rechargeable lithium-ion batteries, which will be shipped at or below 30% charge for safety. Fully charge your shades before use for optimal performance.

Motorized Wand

Downloads

Motorization Instructions

Downloads

SelectConnect App Setup & Product Pairing Instructions

Measuring

Inside Mount Instructions

Measuring the width

The width measurement is taken from the inside edge of the window frame at the top.
If you are getting a 1/16” or 1/32” increment, round down to the nearest 1/8”. (For example, if the smallest measurement is 24 9/16", round down to 24 1/2". If it's 24 3/8", no need to round down.)
This will be the width you order.

Measuring the height

The height measurement is taken from the window frame in three places (top left, center, and top right down to the window sill).
Record the largest height out of the 3 measurements up to the nearest 1/8”.
If you are getting a 1/16” or 1/32” increment, round up to the nearest 1/8”. (For Example, If the largest measurement is 24 9/16", round up to 24 5/8". If it's 24 1/2", no need to round up.)
This will be the height you order.

Outside Mount Instructions

An outside mount is a great choice for better light coverage, since it fully covers the window and frame. To get the right fit, you’ll need to account for a few extra measurements when placing your order. We’ll custom make your shade to the exact dimensions you provide—no automatic additions are made.

Flat Surface Requirements

Start by choosing where you’d like to mount your shade. You’ll need at least 1-2½” of flat mounting space. For more details, check the product page and review the “Specifications” tab.

Measuring the width

Measuring the height

Measuring Tips

Downloads

Measure Instructions

Contact Customer Support

Shipping & Production

Expedite Your Order Today

Free Shipping on Everything

Freight Surcharge Chart	SelectBlinds	Other Retailers
Blinds and shades under 94" wide	Free	Free
Blinds and shades 94" wide & above	Free	$70 per oversize product
Vertical blinds 94" in height or width & above	Free	$70 per oversize product
Some Shutters	Free	$70 per oversize product
